Industrial Hysteresis Dynamometer Electric Motor Dyno

Name: Industrial Hysteresis Dynamometer Electric Motor Dyno
Brand: Shenzhen Precision Motive Technology Co., Ltd.
SKU: PWHD
Price: 3,500.00 USD
Availability: InStock

Brand Name:	Precision Motive
Model Number:	PWHD
MOQ:	1SET
Price:	USD 1000-6000
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Weight:

2.5 -30 Kg

Measurement Range:

0-28N

Resolution:

0.001 N

Accuracy:

±0.05%

Dimensions:

200mm X 300mm X 100mm

Communication Protocol:

MODBUS

Model:

Hysteresis Dynamometer

Power Supply:

110/220V AC

Packaging Details:

25CM*50CM*15CM

Highlight:

industrial hysteresis dynamometer

industrial dynamometer testing equipment

28n hysteresis dynamometer

Product Description

Industrial Hysteresis Dynamometer for High-Performance Measurements

Product Description:

The Hysteresis Dynamometer is a magnetic hysteresis performance analyzer that can be used in research and development of electric motors, generators, and other machinery. It can be used to measure torque, rotational speed, and power output of these machines. It is also useful in measuring the magnetic properties of materials, including hysteresis loops, magnetic losses, and coercive force.

The device is equipped with MODBUS communication protocol that provides seamless integration with other devices in the system. The resolution of the device is 0.001 N, making it an ideal choice for applications that require high precision and accuracy.

The Hysteresis Dynamometer is suitable for a wide range of applications, including product development, quality control, and research and development. It can be used in the automotive industry to test engines and transmissions, in the aerospace industry to test turbines and jet engines, and in the manufacturing industry to test various types of motors and generators.

In conclusion, Precision Motive's Hysteresis Dynamometer model PWHD is a reliable, accurate, and versatile device that can be used in various applications. Its magnetic hysteresis technology makes it an excellent choice for measuring the magnetic properties of materials, while its high accuracy and precision make it an ideal choice for testing various types of machinery.

Features:

Product Name: Hysteresis Dynamometer
Weight: 2.5 -30 Kg
Warranty: 1 Year
Accuracy: ±0.05%
Resolution: 0.001 N
Measurement Range: 0-28N
Keywords: Dynamometer for Magnetic Hysteresis, Hysteresis Dynamometer, Dynamometer Hysteresis Force Meter

Technical Parameters:

Maximum Torque Range and Power of Various Motors

The following table presents the specifications of various motors in terms of their torque range, power output, maximum speed and cooling type.

Model	Maximum Torque Range (Kg.CM)	Five-minute short-term power (W)	Long-term operating power (W)	Maximum Speed (RPM)	Cooling Type
PMHD-101	0.1	35	8	30,000	Fan
PMHD-201	0.2	35	8	30,000	Fan
PMHD-301	0.3	50	12	30,000	Fan
PMHD-501	0.5	50	12	25,000	Fan
PMHD-102	1	90	25	25,000	Fan
PMHD-202	2	90	25	25,000	Fan
PMHD-302	3	250	65	25,000	Fan
PMHD-502	5	250	65	25,000	Fan
PMHD-103	10	400	80	25,000	Fan
PMHD-203	20	580	120	25,000	Fan
PMHD-303	30	700	150	25,000	Fan
PMHD-503	50	1000	200	25,000	Fan
PMAHD-102	1	200	80	25,000	Compressed air
PMAHD-202	2	200	80	25,000	Compressed air
PMAHD-302	3	400	120	25,000	Compressed air
PMAHD-502	5	400	120	25,000	Compressed air
PMAHD-103	10	800	350	25,000	Compressed air
PMAHD-503	50	1500	1200	25,000	Compressed air
PMBHD-303	30	1500	900	25,000	BLOWER
PMBHD-503	50	2000	1800	25,000	BLOWER
PMBHD-603	60	3500	2800	25,000	BLOWER
PMBHD-144	140	14000	3000	12000	BLOWER
PMBHD-284	280	7000	5500	10000	BLOWER
PMBHD-564	560	14000	8000	10000	BLOWER

As seen from the table, there are various models of motors, each with different torque range, power output, and cooling types such as Fan, Compressed air or Blower. It's important to consider these factors before selecting one for your application.

Customization:

Our customization services allow you to tailor the product to your specific needs. Whether you need a Magnetic Hysteresis Power Output Meter or additional features for your testing application, we can work with you to create a solution that meets your requirements.

Product Packaging

The Hysteresis Dynamometer will be securely packaged in a sturdy and durable cardboard box to ensure safe delivery.
All necessary packaging materials, including foam inserts and bubble wrap, will be used to protect the product during transport.
The product packaging will also include an instruction manual and any necessary hardware or accessories.

Shipping

The Hysteresis Dynamometer will be shipped via a reputable courier service, such as FedEx or UPS.
The shipping method will be selected based on the customer's location and delivery preferences.
Customers will receive a tracking number once the product has been shipped, allowing them to track their shipment and receive updates on its delivery status.
Shipping costs will vary depending on the customer's location and the selected shipping method.

FAQ:

Q: What is the brand name of this Hysteresis Dynamometer product?

A: The brand name of this product is Precision Motive.

Q: What is the model number of this product?

A: The model number of this product is PWHD.

Q: Where is this Hysteresis Dynamometer product made?

A: This product is made in China.

Q: What is the measurement range of this Hysteresis Dynamometer?

A: The measurement range of this Hysteresis Dynamometer is 0-500N.

Q: What is the accuracy of this Hysteresis Dynamometer?

A: The accuracy of this Hysteresis Dynamometer is ±0.5% of full scale.
